Bộ lưu điện UPS APC BR500CI-AS: APC Back-UPS RS 500, 230V without auto shutdown software, ASEAN. APC Back-UPS RS, 300 Watts / 500 VA,Input 230V / Output 230V. Typical Backup Time at Full Load 3 minutes (300 Watts)
Thông số kĩ thuật:
Output
Output Power Capacity
300 Watts / 500 VA
Max Configurable Power
300 Watts / 500 VA
Nominal Output Voltage
230V
Output Frequency (sync to mains)
47 - 63 Hz
Topology
Line Interactive
Waveform Type
Stepped approximation to a sinewave
Output Connections
| (3) IEC 320 C13 (Battery Backup) |
Input
Nominal Input Voltage
230V
Input Frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
| IEC-320 C14 |
Cord Length
1.83 meters
Batteries & Runtime
Battery Type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time
10 hour(s)
Replacement Battery
APCRBC125
RBC™ Quantity
1
Runtime Graph
Communications & Management
Audible Alarm
Alarm when on battery : distinctive low battery alarm
Surge Protection and Filtering
Surge energy rating
240 Joules
Physical
Maximum Height
185.00 mm
Maximum Width
115.00 mm
Maximum Depth
213.00 mm
Net Weight
4.90 KG
Shipping Weight
5.50 KG
Shipping Height
257.00 mm
Shipping Width
190.00 mm
Shipping Depth
291.00 mm
Master Carton Units
1.00
