Thông số kỹ thuật:
Feature | Description |
Form Factor | Single-wide GRWIC, no slot restrictions |
Dimensions (W x H x D) | 3.25 x 2.0 x 8.5 in |
Weight | 0.9 lb (0.4 kg) |
LEDs | • ISDN BRI U GRWIC
• B1 and B2 for ISDN channel status
• NT1 for connection status
|
Ports | Single RJ-49C port |
Environmental Specifications | |
Operating Conditions | |
Operating Temperature | 32º F to 104º F (0 to +40º C) continuous operating temperature range |
Shock and Vibration | 30 G @11 ms |
Altitude | 10,000 ft (3,048 m); maximum operating temperature is de-rated with increasing altitude per |
Relative Humidity | 5 to 85 percent non-condensing |
Non-Operating Conditions | |
Temperature | 32º F to 104º F (0º C to40º C) |
Relative Humidity | 5 to 85 percent non-condensing |
Altitude | 10,000 ft (3,048 m); maximum operating temperature is de-rated with increasing altitude per |
Non-Operating Free-Fall Drop | 4 in. (100 mm) per ENG-339611 |
Operating Seismic Earthquake | IEC 61850-3 section 5.5 |
Non-Operating Shock and Vibration | 40-50G (3.26 m/s minimum) |
Immunity | • EN61000-6-2 • EN61000-4-2 (ESD) • EN61000-4-3 (RF) • EN61000-4-4 (EFT) • EN61000-4-5 (SURGE) • EN61000-4-6 (CRF) • EN61000-4-11 (VDI) • EN 55024, CISPR 24 • EN50082-1 |
Telecom Compliance | • US: TIA-968-A • CA: CS-03 • EU: TBR1, 2, 4, 12, 13 • RTTE Directive • Australia: AS/ASIF S016, S038 • Japan: JATE |
Safety | • USA: UL 60950-1 • Canada: CAN/CSA C22.2 No. 60950-1 • Europe: EN 60950-1 • China: GB 60950-1 • Australia/New Zealand: AS/NZS 60950-1 • Rest of World: IEC 60950-1 • CSA certified to UL/CSA 60950-1, 2nd Ed. • CB report to IEC60950-1, 2nd Ed., covering all group differences and national deviations |
Electromagnetic Compliance | • 47 CFR, Part 15 • ICES-003 Class A • EN55022 Class A • CISPR22 Class A • AS/NZS 3548 Class A • VCCI V-3 • CNS 13438 • EN 300-386 |
