Giới thiệu chung về Card Router Cisco HWIC-AP-AG-B:
HWIC-AP-AG-B
- The Cisco HWIC-AP 802.11G and HWIC-AP 802.11A/B/G are Wireless LAN interface cards in the HWIC (High-Speed WAN Interface Card) form factor providing integrated Access Point functionality in the Cisco 1800 (Modular), Cisco 2800, and Cisco 3800 Integrated Services Routers. Enterprise branch office and small-to-medium business customers can run concurrent services of Layer 3 routing, security, Layer 2 switching and now IEEE 802.11 wireless LAN functionality in a single platform. This combination offers ease of configuration, deployment, and management while delivering high performance, security and rich set of services.
- The Cisco 802.11 WLAN Interface Card provides Cisco 1800 Modular, 2800 and 3800 Integrated Services Routers the following:
- Integrated Secure WLAN Access Point Functionality for Cisco's Modular Integrated Services Routers
- Single Band 802.11b/g or Dual Band 802.11a/b/g radios
- Support for fixed or external dipole or dual mode antennas
- Extensive WLAN Security Capabilities:
- WEP, TKIP, Key Management
- WAP2/AES
- 802.1X
- LEAP, PEAP, EAP-TLS, EAP-FAST, EAP-TTLS, EAP-SIM, EAP-MD5
- Multiple VLAN support
- AAA Radius/Accounting
- Thông số chi tiết Card Router Cisco HWIC-AP-AG-B:
General Information | |
Manufacturer: | Cisco |
Product ID: | HWIC-AP-AG-B |
Product Description: | AP HWIC, 2 radios( 2.4/5Ghz Radios 802.11 a/b/g) FCC |
Product Type: | Wireless Module |
Marketing Information | |
The HWIC-AP 802.11a/b/g is a Wireless LAN interface card in the HWIC (High-Speed WAN Interface Card) form factor providing integrated Access Point functionality in the Cisco 1800 (Modular), Cisco 2800, and Cisco 3800 Integrated Services Routers. Enterprise branch office and small-to-medium business customers can run concurrent services of Layer 3 routing, security, Layer 2 switching and now IEEE 802.11 wireless LAN functionality in a single platform. This combination offers ease of configuration, deployment, and management while delivering high performance, security and rich set of services. | |
Wireless Specifications | |
Wi-Fi: | Yes |
Wi-Fi Standard: | IEEE 802.11a/b/g |
Number of Antennas: | 2 |
Antenna Connector: | RP-TNC |
Maximum Antenna Range: | 2000 ft |
ISM Band: | Yes |
UNII Band: | Yes |
ISM Minimum Frequency: | 2.41 GHz |
ISM Maximum Frequency: | 2.46 GHz |
UNII Minimum Frequency: | 5.15 GHz |
UNII Maximum Frequency: | 5.83 GHz |
Wireless Transmission Speed: | 54 Mbps |
Wireless Security: | WPA |
WEP | |
Management & Protocols | |
Security Features: | RADIUS |
AES | |
Physical Characteristics | |
Height: | 0.8" |
Width: | 3.1" |
Depth: | 4.9" |
Weight (Approximate): | 5.76 oz |
Miscellaneous | |
Additional Information: | · Spare Product · SSIDs: 6 · Wireless VLANs: 6 · SNMP v1, v2, and v3 support · Telnet interface support · Support is provided by the CiscoWorks LAN Management Solution Non-Overlapping Channels: · 802.11a: up to 12 · 802.11b/g: 3 |
Device Supported: | Router |
